Nebu - piston nebulizer for aerosol

Product Description

Piston device for aerosol therapy that can be used by the whole family.

Features

Aerosol therapy is a technique for administering one or more aerosols. drugs directly and in a targeted manner into the respiratory tract, through inhalation.
It is indicated for the prevention and treatment of numerous pathologies affecting the upper airways (throat, larynx, pharynx) and lower airways (bronchi, bronchioles, pulmonary alveoli).
The drug, liquid or solid, is nebulized and reduced to many very fine particles using a device called a "nebulizer".
Zentiva Nebu is a compact piston aerosol device for the whole family:

• Practical and simple to use;
• Compact, lightweight, space-saving and suitable for transport.

Technical details

• Rated voltage: 230 V~
• Current consumption: 1A
• Maximum flow: 13.5 ± 2 1/min
• Maximum pressure: 2.2 ± 0.6 atm
• Appliance operating conditions: 20'ON-40'OFF at 40°C
• MMAD: <3.7 μm
• Ampoule capacity: 10 ml Max; 2ml Min
• Useful life in service of the device: 1,000 cycles/therapies
• Useful life in service of the accessories: 1 year
• Useful life in storage: 5 years
• Frequency: 50Hz
• Fuse: T1 H 250V, 5x20mm
• Operating flow: 6 + 1 l/min
• Operating pressure: 0.65 ± 0.2 atm
• Weight: 1.2 Kg
• Respirable fraction: 65.7 % ± 3.4
• Noise level at 50cm*: 68 dB

*The noise data were measured with a new device.
The values ​​may vary over time with use.

The product is a CE Medical Device.

Format

Package contents:

• Zentiva Nebu piston device;
• Adult and child mask;
• Ampoule;
• Filters;
• Multilingual user manual.
