Automatic arm blood pressure monitor nissei ds-11

Product Description

DS-11 is a basic device for commercial positioning only, but in fact, with functional and accessory features typical of higher product ranges.

Indications

DS-11 digital blood pressure measurement, thanks to the use of the most innovative and comfortable inflation measurement technology, motion detection functions during measurement, arrhythmia detection, average of the last three measurements, but also important accessories such as the larger cuff for use on diameters from 22 to 42 cm.
Completely automatic in measuring and recording results, it has an extremely intuitive and essential user interface, as well as being easy to use. to be able to independently measure blood pressure in a simple and comfortable way, with a consequent improvement in the reliability of the data, detected by the device using the oscillometric method.
The device's inflation technology works by inflating the cuff to a value just sufficient to detect blood pressure and heart rate, thus identifying The diastolic pressure value is detected first, then gradually inflated until the systolic pressure value is identified. Immediately after, inflation is stopped and the cuff is rapidly deflated.
With this system, the measurement is extremely "comfortable", so much so that the procedure is completed before the patient has time to perceive the cuff inflation as "constrictive".
The larger cuff makes the product immediately usable over a wide range of arm sizes, thus avoiding the purchase of an additional accessory by a good number of patients with a "large" arm size.
As already mentioned, the data recorded by the device is automatically stored in memory (up to a maximum of 60 measurements), as is the calculation of the average value of the last 3 measurements in memory.
The DS-11 also has a large cuff size. Like all Nissei devices distributed by CA-MI, it boasts ESH Clinical Validation of Accuracy in accordance with the most recent international protocol 2010.

Technical characteristics

Dimensions: 11.65x12.22x6.99 cm.
LCD display.
Application arm diameter: 22-42 cm.
Weight: 250 g (main unit only, not including batteries).
Measurement method: oscillometric.
Inflation/deflation method: automatic on the rise (inflationary).
Pressure measurement range: 50-250 mmHg (systolic) | 40-180 mmHg (diastolic).
Cuff pressure range: 3-300 mmHg.
Heart rate measurement range: 40-180 bpm (pulse rate).
Pressure measurement accuracy: ± 3 mmHg.
Heart rate accuracy: ± 5% of reading.
Memories: 60 measurements recorded on a single channel automatically.
Power supply: 4 AA alkaline batteries - 1.5 V (AC/DC adapter optional).

The package contains:

• 1 central unit
• 1 cuff.
